INCONEL 625 Slip On Flanges are slipped over the pipe and then welded both inside and outside to provide sufficient strength and prevent leakage. Due to its lower cost and the fact that less accuracy is required when cutting pipe to length, these INCONEL 625 slip on flanges are preferred over weld neck flanges. Tesco Steel & Engineering manufacture a wide range of high quality 2.4856 Slip On Flanges in India. We offer these flanges in ASME/ANSI/DIN standards.
| C | Mn | Si | S | Cu | Fe | Ni | Cr |
|---|---|---|---|---|---|---|---|
| 0.10 max | 0.50 max | 0.50 max | 0.015 max | - | 5.00 max | 58.00 min | 20.00-23.00 |
| Tensile Strength, MPa | Yield Strength, Min, Mpa | Elongation % min. |
|---|---|---|
| 930 | 517 | 42.5 |
| Standard | Werkstoff Nr. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4MNiCr22Mo9Nb | NiCr23Fe |
| Inconel 625 Slip On Flanges are available in the following specifications: | |
|---|---|
| Size | 1/2"NB to 56"NB |
| Class | 150#, 300#, 3000#, 6000#, 9000# |
| Sch (Schedule) | XS, XXS, STD & Schedule 20, 40, 80, 160 |
| Pressure Ratings | PN 1 - PN 400 |
| Other Services | Hot Dip Galvanized (GI) Inconel 625 Slip On Flanges Sand Blasting on Inconel 625 Slip On Flanges Shot Peening on Inconel 625 Slip On Flanges Epoxy Coating on Inconel 625 Slip On Flanges FBE Coating on Inconel 625 Slip On Flanges |
| ANSI / ASME Class 150 Inconel 625 Slip On Flange |
| ANSI / ASME Class 300 Inconel 625 Slip On Flange |
| ANSI / ASME Class 600 Inconel 625 Slip On Flange |
| ANSI / ASME Class 1500 Inconel 625 Slip On Flange |
